AWS Lambda + API Gateway Integration Tutorial: Complete Guide to Building REST APIs

Introduction: Why This Combination Is So Popular

Want to build a scalable API in 10 minutes?

Lambda + API Gateway is the fastest way.

No server setup needed, no scaling concerns, no load balancer configuration.

Write your code, set up routing, deploy. Your API is live.

That's the magic of Serverless APIs.

If you're not familiar with Lambda basics, consider reading AWS Lambda Complete Guide first.

Concept Introduction

Before diving in, understand how these two services work together.

What is API Gateway

API Gateway is AWS's API management service.

It handles:

• Receiving Requests: Processing HTTP/HTTPS requests
• Authentication & Authorization: Validating API Keys, JWT Tokens, IAM permissions
• Traffic Control: Rate limiting, throttling protection
• Request Transformation: Modifying request/response formats
• Monitoring & Logging: CloudWatch integration, access logs

Simply put, API Gateway is the "front door" to your API.

All external requests pass through it first, then forward to backend services (Lambda, EC2, other HTTP endpoints).

REST API vs HTTP API Differences

API Gateway has two types: REST API and HTTP API.

Feature	REST API	HTTP API
Price	$3.50 per million	$1.00 per million
Latency	Higher	Lower (~60% faster)
Features	Complete	Basic
API Key Management	✅	✅
Usage Plans	✅	❌
Request Validation	✅	❌
WAF Integration	✅	❌
Private Endpoints	✅	✅
Lambda Authorizer	✅	✅

Selection Recommendations:

• Need advanced features (WAF, request validation, usage plans): Choose REST API
• Prioritizing low cost and low latency: Choose HTTP API
• Not sure: Start with HTTP API, upgrade when needed

For detailed cost comparison, see AWS Lambda Pricing Complete Guide.

Lambda Proxy Integration Principle

Lambda Proxy Integration is the most commonly used integration method.

The principle is straightforward:

1. API Gateway receives HTTP request
2. Wraps complete request (including headers, body, path, query) into event object
3. Passes to Lambda function
4. Lambda returns response in specified format
5. API Gateway sends response to client

event object example:

{
  "httpMethod": "POST",
  "path": "/users",
  "headers": {
    "Content-Type": "application/json",
    "Authorization": "Bearer xxx"
  },
  "queryStringParameters": {
    "page": "1"
  },
  "body": "{\"name\": \"John\"}"
}

Lambda response format (must follow):

{
  "statusCode": 200,
  "headers": {
    "Content-Type": "application/json"
  },
  "body": "{\"message\": \"success\"}"
}

If the response format is incorrect, you'll get a 502 Bad Gateway error. This is the most common issue.

---

Implementation Steps

Let's build a simple API: GET /hello returns a greeting message.

Step 1: Create Lambda Function

Using AWS Console:

1. Go to Lambda service
2. Click "Create function"
3. Select "Author from scratch"
4. Function name: hello-api
5. Runtime: Python 3.12
6. Click "Create function"

Paste the code:

import json

def lambda_handler(event, context):
    # Get query parameters
    name = "World"
    if event.get("queryStringParameters"):
        name = event["queryStringParameters"].get("name", "World")

    # Create response
    response = {
        "statusCode": 200,
        "headers": {
            "Content-Type": "application/json",
            "Access-Control-Allow-Origin": "*"  # CORS
        },
        "body": json.dumps({
            "message": f"Hello, {name}!",
            "path": event.get("path", ""),
            "method": event.get("httpMethod", "")
        })
    }

    return response

Click "Deploy" to save.

Step 2: Create API Gateway

Create HTTP API (recommended for beginners):

1. Go to API Gateway service
2. Click "Create API"
3. Select "HTTP API" → "Build"
4. Add integration: Select "Lambda"
5. Select the hello-api function you just created
6. API name: my-hello-api
7. Click "Next"

Step 3: Configure Routes

On the route configuration page:

1. Method: GET
2. Resource path: /hello
3. Integration target: hello-api (Lambda function)
4. Click "Next"

Step 4: Deploy and Test

1. Stage name: $default (or custom like prod)
2. Click "Next" → "Create"

After completion, you'll see an Invoke URL like:

https://abc123xyz.execute-api.ap-northeast-1.amazonaws.com

Test the API:

# Basic test
curl https://abc123xyz.execute-api.ap-northeast-1.amazonaws.com/hello

# Test with parameters
curl "https://abc123xyz.execute-api.ap-northeast-1.amazonaws.com/hello?name=Claude"

If you see a JSON response, congratulations! Your Serverless API is live.

---

Want to make your API architecture more robust? Book architecture consultation and let experts help you design it.

---

Lambda Authorizer in Practice

The API is live, but anyone can access it.

Let's add authentication.

Token-based vs Request-based

Lambda Authorizer has two types:

Token-based Authorizer:

• Gets token from Authorization header
• Validates JWT, OAuth tokens, etc.
• Suitable for standard Bearer Token authentication

Request-based Authorizer:

• Can access complete request (headers, query, path)
• Suitable for complex authentication logic
• Example: Authenticate based on IP + API Key combination

JWT Validation Implementation Example

Here's an Authorizer that validates JWT Tokens:

import json
import jwt  # Needs PyJWT installed in Lambda Layer

SECRET_KEY = "your-secret-key"  # In production, store in Secrets Manager

def lambda_handler(event, context):
    try:
        # Get token
        token = event.get("authorizationToken", "")
        if token.startswith("Bearer "):
            token = token[7:]

        # Validate JWT
        payload = jwt.decode(token, SECRET_KEY, algorithms=["HS256"])
        user_id = payload.get("sub")

        # Validation successful, return Allow policy
        return generate_policy(user_id, "Allow", event["methodArn"])

    except jwt.ExpiredSignatureError:
        raise Exception("Unauthorized")  # Token expired
    except jwt.InvalidTokenError:
        raise Exception("Unauthorized")  # Token invalid

def generate_policy(principal_id, effect, resource):
    return {
        "principalId": principal_id,
        "policyDocument": {
            "Version": "2012-10-17",
            "Statement": [{
                "Action": "execute-api:Invoke",
                "Effect": effect,
                "Resource": resource
            }]
        },
        "context": {
            "userId": principal_id  # Can pass additional info to backend Lambda
        }
    }

IAM Policy Return Format

Authorizer must return a specific IAM Policy format:

{
  "principalId": "user123",
  "policyDocument": {
    "Version": "2012-10-17",
    "Statement": [
      {
        "Action": "execute-api:Invoke",
        "Effect": "Allow",
        "Resource": "arn:aws:execute-api:region:account:api-id/stage/method/path"
      }
    ]
  },
  "context": {
    "userId": "user123",
    "role": "admin"
  }
}

Key Points:

• Effect can only be Allow or Deny
• context values can only be strings, numbers, or booleans
• For authentication failures, directly raise Exception("Unauthorized")

Lambda Function URL vs API Gateway

In 2022, AWS introduced Lambda Function URLs.

This allows Lambda to handle HTTP requests directly, without API Gateway.

Feature Comparison Table

Feature	Function URL	API Gateway
Cost	Free	$1-3.5/million
Setup Complexity	Simple	Medium
Custom Domain	More complex	Built-in support
Rate Limiting	❌	✅
API Key Management	❌	✅
Caching	❌	✅
Request Validation	❌	✅
WAF Integration	Requires CloudFront	✅
Lambda Authorizer	❌	✅
IAM Authentication	✅	✅

When to Use Function URL

Scenarios suited for Function URL:

• Internal service-to-service calls
• Simple Webhook receivers
• Development/test environments
• Cost-sensitive low-traffic services

Setting up Function URL:

1. Go to Lambda function configuration
2. Select "Configuration" → "Function URL"
3. Click "Create function URL"
4. Auth type: Choose NONE (public) or AWS_IAM
5. Click "Save"

You'll get a URL like: https://xxx.lambda-url.ap-northeast-1.on.aws/

When You Must Use API Gateway

Scenarios requiring API Gateway:

• Need rate limiting to protect API
• Need API Keys or usage plans
• Need WAF protection
• Need custom domains (simpler setup)
• Need Lambda Authorizer
• Need request/response transformation
• Need caching to reduce Lambda invocations

Rule of Thumb:

• Public-facing APIs: Use API Gateway
• Internal service calls: Consider Function URL

---

Not sure which to choose? API architecture choices affect cost and scalability.

Book architecture consultation and let us analyze the best solution for you.

---

Performance Optimization

After the API is live, let's optimize performance.

Keep-Alive Connections

Lambda should reuse HTTP connections when calling external services.

Python Example:

import urllib3

# Create connection pool outside handler
http = urllib3.PoolManager()

def lambda_handler(event, context):
    # Reuse connection
    response = http.request('GET', 'https://api.example.com/data')
    return {
        'statusCode': 200,
        'body': response.data.decode('utf-8')
    }

This reduces connection establishment time for each request.

Response Compression

For larger responses, enabling compression can reduce transfer time.

API Gateway Settings:

1. Go to API settings
2. Minimum compression size: Set to 0 (or appropriate value like 1024)
3. Deploy API

Lambda Response:

import gzip
import base64

def lambda_handler(event, context):
    # Check if client supports gzip
    accept_encoding = event.get('headers', {}).get('accept-encoding', '')

    body = '{"data": "large response content..."}'

    if 'gzip' in accept_encoding:
        compressed = gzip.compress(body.encode())
        return {
            'statusCode': 200,
            'headers': {
                'Content-Type': 'application/json',
                'Content-Encoding': 'gzip'
            },
            'body': base64.b64encode(compressed).decode(),
            'isBase64Encoded': True
        }

    return {
        'statusCode': 200,
        'body': body
    }

Cache Configuration

For rarely-changing data, enabling API Gateway caching can significantly reduce Lambda invocations.

REST API Cache Settings:

1. Go to stage settings
2. Enable API caching
3. Select cache capacity (0.5GB ~ 237GB)
4. Set TTL (time to live)

Note: Caching has additional costs (starting at $0.02/hour).

If you want to manage these settings with Infrastructure as Code, see Terraform AWS Lambda Deployment Complete Tutorial.

---

Common Error Handling

Even with correct setup, errors can still occur.

502 Bad Gateway

This is the most common error.

Cause 1: Response Format Error

Lambda must return the correct format:

# Error: Returning string directly
return "Hello World"

# Correct: Return specified format
return {
    "statusCode": 200,
    "headers": {"Content-Type": "application/json"},
    "body": json.dumps({"message": "Hello World"})
}

Cause 2: body is Not a String

# Error: body is dict
return {
    "statusCode": 200,
    "body": {"message": "Hello"}  # This causes 502
}

# Correct: body must be string
return {
    "statusCode": 200,
    "body": json.dumps({"message": "Hello"})
}

Cause 3: Lambda Execution Error

Check CloudWatch Logs for actual error messages.

For complete error handling guide, see AWS Lambda Error Handling Complete Guide.

CORS Issues

Cross-origin requests will encounter CORS errors.

Solution 1: Add CORS headers in Lambda response

return {
    "statusCode": 200,
    "headers": {
        "Content-Type": "application/json",
        "Access-Control-Allow-Origin": "*",
        "Access-Control-Allow-Methods": "GET, POST, OPTIONS",
        "Access-Control-Allow-Headers": "Content-Type, Authorization"
    },
    "body": json.dumps(data)
}

Solution 2: Configure CORS in API Gateway

HTTP API:

1. Go to API Settings → CORS
2. Configure Access-Control-Allow-Origin
3. Set allowed Methods and Headers

REST API:

1. Select resource
2. Click "Enable CORS"
3. Configure allowed origins and headers

Key Point: OPTIONS preflight requests must also respond correctly.

FAQ

What's the latency of Lambda + API Gateway?

Under normal conditions, API Gateway adds about 10-30ms latency. Plus Lambda Cold Start (first invocation or after idle), it may add 100-500ms. Use Provisioned Concurrency or SnapStart (Java) to eliminate Cold Start.

Can REST API and HTTP API be converted?

Cannot convert directly, but can migrate. For new projects, recommend HTTP API directly (unless you need REST API-specific features), saving 70% on API Gateway costs.

How to set Lambda Authorizer cache time?

Set TTL (0-3600 seconds) when creating the Authorizer. Setting to 0 means no caching, Authorizer is called for every request. Recommend setting appropriate cache time (like 300 seconds) to reduce costs.

Can Function URL bind to custom domain?

Yes, but requires CloudFront configuration. In comparison, API Gateway's custom domain setup is more direct and simpler.

---

Conclusion: Building Stable Serverless APIs

The Lambda + API Gateway combination has been validated by countless enterprises.

From small startups to large enterprises, this architecture handles millions of API requests daily.

Key Success Factors:

1. Choose the Right API Type: HTTP API suits most scenarios
2. Handle Response Format Correctly: Avoid 502 errors
3. Implement Appropriate Authentication: Protect your API
4. Monitor and Optimize: Continuously improve performance and cost

Next Steps:

• Learn Error Handling Best Practices
• Understand Event-Driven Architecture for async tasks
• Use Terraform for automated deployment

---

Need Professional API Architecture Planning?

If you're:

• Designing new API architecture
• Evaluating Lambda + API Gateway suitability
• Optimizing existing API performance and cost

Book architecture consultation, we'll respond within 24 hours.

Good API architecture significantly reduces maintenance costs.

---

References

1. AWS Official Documentation: API Gateway Developer Guide
2. AWS Official Documentation: Lambda Proxy Integration
3. AWS Official Documentation: Lambda Authorizers
4. AWS Official Documentation: Lambda Function URLs
5. AWS Blog: Choosing between REST APIs and HTTP APIs
