Kubernetes Core Objects Complete Tutorial: Master Pod, Deployment & Service

To learn Kubernetes, the most important thing is understanding "objects."

Pod, Deployment, Service... these terms are easy to confuse at first. But once you understand their respective roles, Kubernetes becomes much clearer.

This article will walk you through the most important core objects in Kubernetes.

For a basic introduction to Kubernetes, see Kubernetes Complete Guide. For architecture explanation, see Kubernetes Architecture Complete Guide.

---

Pod Complete Analysis

Pod is the most basic deployment unit in Kubernetes.

What is a Pod

One-sentence explanation: A Pod is a combination of one or more containers, the smallest unit Kubernetes schedules.

Key understanding:

• You don't directly deploy containers—you deploy Pods
• Containers in a Pod share network and storage
• Pods are ephemeral and can be deleted and recreated at any time

Feature	Description
Smallest unit	Kubernetes doesn't manage individual containers, it manages Pods
Shared network	Containers in same Pod communicate via localhost
Shared storage	Can mount the same Volume
Ephemeral	When a Pod dies, it's gone

Single-Container vs Multi-Container Pod

Single-container Pod (most common):

Only one container in a Pod. This is the case 90%+ of the time.

apiVersion: v1
kind: Pod
metadata:
  name: nginx-pod
spec:
  containers:
  - name: nginx
    image: nginx:1.25
    ports:
    - containerPort: 80

Multi-container Pod:

Used only when multiple containers need to work closely together.

Pattern	Description	Example
Sidecar	Assists main container	Log collection, proxy
Ambassador	Proxy external connections	Database proxy
Adapter	Standardize output	Metrics conversion

Sidecar example:

apiVersion: v1
kind: Pod
metadata:
  name: app-with-logging
spec:
  containers:
  - name: app
    image: my-app:1.0
    volumeMounts:
    - name: logs
      mountPath: /var/log/app
  - name: log-collector
    image: fluentd:latest
    volumeMounts:
    - name: logs
      mountPath: /var/log/app
  volumes:
  - name: logs
    emptyDir: {}

Main container writes logs, Sidecar container collects logs. Both containers share the same Volume.

Pod Lifecycle

Pods have clear lifecycle states:

State	Description
Pending	Accepted, but containers not ready
Running	At least one container is running
Succeeded	All containers completed successfully
Failed	At least one container failed
Unknown	Cannot get Pod status

Lifecycle flow:

Create Pod
    ↓
Pending (scheduling, downloading images)
    ↓
Running (containers executing)
    ↓
Succeeded / Failed / Deleted

Important concept:

Pods don't "repair" themselves. If a Pod dies, it's dead. A new Pod will be created to replace it (if you're using Deployment).

Complete Pod YAML Example

apiVersion: v1
kind: Pod
metadata:
  name: my-app
  labels:
    app: my-app
    environment: production
spec:
  containers:
  - name: app
    image: my-app:1.0
    ports:
    - containerPort: 8080
    resources:
      requests:
        memory: "128Mi"
        cpu: "250m"
      limits:
        memory: "256Mi"
        cpu: "500m"
    env:
    - name: DATABASE_URL
      valueFrom:
        secretKeyRef:
          name: db-secret
          key: url
    livenessProbe:
      httpGet:
        path: /health
        port: 8080
      initialDelaySeconds: 30
      periodSeconds: 10
    readinessProbe:
      httpGet:
        path: /ready
        port: 8080
      initialDelaySeconds: 5
      periodSeconds: 5
  restartPolicy: Always

Important field descriptions:

Field	Purpose
labels	Labels for selection and classification
resources	Resource requests and limits
env	Environment variables
livenessProbe	Liveness check
readinessProbe	Readiness check
restartPolicy	Restart policy

---

Deployment Deep Dive

In practice, you almost never create Pods directly. You create Deployments.

Why Deployment

Problems with creating Pods directly:

Problem	Description
No auto-restart	Pod dies, it's gone
No scaling mechanism	Can't easily increase/decrease count
Updates are troublesome	Must manually delete old, create new
No version control	Can't rollback

Deployment solves these problems:

Feature	Description
Auto-maintain count	One dies, one is created
Declarative scaling	Just change a number
Rolling updates	Zero-downtime updates
Version history	Can quickly rollback

Role of ReplicaSet

Deployment doesn't directly manage Pods—it manages ReplicaSets, and ReplicaSets manage Pods.

Deployment
    ↓ manages
ReplicaSet
    ↓ manages
Pod, Pod, Pod

Why this design?

During updates, Deployment creates a new ReplicaSet and gradually transfers Pods from the old ReplicaSet to the new one. The old ReplicaSet is kept for easy rollback.

Deployment YAML Example

apiVersion: apps/v1
kind: Deployment
metadata:
  name: my-app
  labels:
    app: my-app
spec:
  replicas: 3
  selector:
    matchLabels:
      app: my-app
  template:
    metadata:
      labels:
        app: my-app
    spec:
      containers:
      - name: app
        image: my-app:1.0
        ports:
        - containerPort: 8080
        resources:
          requests:
            memory: "128Mi"
            cpu: "250m"
          limits:
            memory: "256Mi"
            cpu: "500m"
  strategy:
    type: RollingUpdate
    rollingUpdate:
      maxSurge: 1
      maxUnavailable: 0

Key fields:

Field	Description
replicas	How many Pods to maintain
selector	What labels to select Pods with
template	Pod template
strategy	Update strategy

Rolling Update Mechanism

When you update a Deployment (e.g., change the image):

kubectl set image deployment/my-app app=my-app:2.0

Rolling update process:

Initial state: 3 v1 Pods

Step 1: Create 1 v2 Pod
v1: ●●●
v2: ●

Step 2: After v2 is Ready, delete 1 v1
v1: ●●
v2: ●

Step 3: Create 2nd v2
v1: ●●
v2: ●●

Step 4: Delete 1 v1
v1: ●
v2: ●●

Step 5: Create 3rd v2
v1: ●
v2: ●●●

Step 6: Delete last v1
v1:
v2: ●●●

Complete!

Strategy parameters:

Parameter	Description	Example Value
maxSurge	Max extra Pods allowed	1 or 25%
maxUnavailable	Max missing Pods allowed	0 or 25%

Rollback Operations

Update has problems? Rollback quickly.

# View update history
kubectl rollout history deployment/my-app

# Rollback to previous version
kubectl rollout undo deployment/my-app

# Rollback to specific version
kubectl rollout undo deployment/my-app --to-revision=2

# Check rollback status
kubectl rollout status deployment/my-app

---

Need Kubernetes architecture planning?

Correct object design affects system maintainability and stability. Let experts help you plan.

Book architecture consultation

---

Service Network Access

We have Pods, but how does the outside world access them? That's Service's job.

Necessity of Service

Problem: Pod IPs change.

• Pod IP changes after restart
• Pod IP changes when rescheduled to another Node
• New Pods have new IPs when scaling

Service provides stable access points:

Feature	Description
Fixed IP	Service's ClusterIP doesn't change
DNS name	Access by name, like my-service
Load balancing	Auto-distribute traffic to backend Pods

ClusterIP, NodePort, LoadBalancer

Kubernetes provides three Service types:

Type	Access Method	Use Case
ClusterIP	Cluster internal IP	Internal services (default)
NodePort	Node IP + Port	Testing, development
LoadBalancer	External load balancer	Production external services

ClusterIP example:

apiVersion: v1
kind: Service
metadata:
  name: my-app-service
spec:
  type: ClusterIP
  selector:
    app: my-app
  ports:
  - port: 80
    targetPort: 8080

Only accessible from inside cluster: http://my-app-service:80

NodePort example:

apiVersion: v1
kind: Service
metadata:
  name: my-app-nodeport
spec:
  type: NodePort
  selector:
    app: my-app
  ports:
  - port: 80
    targetPort: 8080
    nodePort: 30080

Accessible from external: http://<node-ip>:30080

LoadBalancer example:

apiVersion: v1
kind: Service
metadata:
  name: my-app-lb
spec:
  type: LoadBalancer
  selector:
    app: my-app
  ports:
  - port: 80
    targetPort: 8080

Cloud will automatically create load balancer and assign external IP.

Service and Endpoints

How does Service know which Pods to send traffic to?

Through Label Selector:

# Service
spec:
  selector:
    app: my-app  # Select Pods with this label

Endpoints auto-maintained:

Kubernetes automatically creates and maintains Endpoint objects, recording Pod IPs that match the selector.

# View Endpoints
kubectl get endpoints my-app-service

Output:

NAME             ENDPOINTS                                   AGE
my-app-service   10.1.0.5:8080,10.1.0.6:8080,10.1.0.7:8080  1h

Traffic path:

Client → Service IP → kube-proxy → Pod IP

---

ConfigMap and Secret

Applications need configuration. Hardcoding config in containers isn't a good idea.

Externalizing Configuration

Why externalize configuration?

Problem	Description
Environment differences	Dev, test, prod have different settings
Security	Passwords shouldn't be in code
Flexibility	Change config without rebuilding image

Kubernetes solution:

Object	Purpose
ConfigMap	General settings (non-sensitive)
Secret	Sensitive information (passwords, keys)

ConfigMap Usage

Create ConfigMap:

apiVersion: v1
kind: ConfigMap
metadata:
  name: app-config
data:
  DATABASE_HOST: "db.example.com"
  DATABASE_PORT: "5432"
  LOG_LEVEL: "info"
  config.json: |
    {
      "feature_flags": {
        "new_ui": true
      }
    }

Usage Method 1: Environment Variables

apiVersion: v1
kind: Pod
metadata:
  name: my-app
spec:
  containers:
  - name: app
    image: my-app:1.0
    env:
    - name: DATABASE_HOST
      valueFrom:
        configMapKeyRef:
          name: app-config
          key: DATABASE_HOST
    # Or load all at once
    envFrom:
    - configMapRef:
        name: app-config

Usage Method 2: Mount as Files

apiVersion: v1
kind: Pod
metadata:
  name: my-app
spec:
  containers:
  - name: app
    image: my-app:1.0
    volumeMounts:
    - name: config-volume
      mountPath: /etc/config
  volumes:
  - name: config-volume
    configMap:
      name: app-config

ConfigMap contents become files under /etc/config/.

Secret Usage

Create Secret:

apiVersion: v1
kind: Secret
metadata:
  name: db-credentials
type: Opaque
data:
  username: YWRtaW4=      # base64 encoded "admin"
  password: cGFzc3dvcmQ=  # base64 encoded "password"

Create with kubectl (more convenient):

kubectl create secret generic db-credentials \
  --from-literal=username=admin \
  --from-literal=password=password

Usage:

apiVersion: v1
kind: Pod
metadata:
  name: my-app
spec:
  containers:
  - name: app
    image: my-app:1.0
    env:
    - name: DB_USERNAME
      valueFrom:
        secretKeyRef:
          name: db-credentials
          key: username
    - name: DB_PASSWORD
      valueFrom:
        secretKeyRef:
          name: db-credentials
          key: password

Secret Security

Important reminders:

Fact	Description
Base64 is not encryption	Anyone can decode
etcd not encrypted by default	Secrets stored in plaintext
Extra measures needed	Enable etcd encryption, use external tools

Ways to enhance security:

Method	Description
etcd encryption	Enable encryption at rest
RBAC	Restrict who can read Secrets
External solutions	HashiCorp Vault, AWS Secrets Manager
Sealed Secrets	Safe to store in Git

---

Having K8s config management difficulties?

Correct config management is the foundation of stable operations. Let us help you establish best practices.

Book a free consultation

---

Other Important Objects

Besides the core objects above, there are several commonly used objects to know.

Namespace

Purpose: Logically isolate resources

apiVersion: v1
kind: Namespace
metadata:
  name: production

Use cases:

Scenario	Example
Environment isolation	dev, staging, production
Team isolation	team-a, team-b
Project isolation	project-x, project-y

Common commands:

# List all namespaces
kubectl get namespaces

# Operate in specific namespace
kubectl get pods -n production

# Set default namespace
kubectl config set-context --current --namespace=production

PersistentVolume and PVC

Pods are ephemeral, but some data needs persistent storage.

PersistentVolume (PV): Storage space provided by cluster administrator

apiVersion: v1
kind: PersistentVolume
metadata:
  name: my-pv
spec:
  capacity:
    storage: 10Gi
  accessModes:
    - ReadWriteOnce
  persistentVolumeReclaimPolicy: Retain
  storageClassName: standard
  hostPath:
    path: /data/my-pv

PersistentVolumeClaim (PVC): User request for storage

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: my-pvc
spec:
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 5Gi
  storageClassName: standard

Use in Pod:

apiVersion: v1
kind: Pod
metadata:
  name: my-app
spec:
  containers:
  - name: app
    image: my-app:1.0
    volumeMounts:
    - name: data
      mountPath: /data
  volumes:
  - name: data
    persistentVolumeClaim:
      claimName: my-pvc

Ingress

Purpose: HTTP/HTTPS routing, more flexible than LoadBalancer

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: my-ingress
spec:
  rules:
  - host: api.example.com
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: api-service
            port:
              number: 80
  - host: web.example.com
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: web-service
            port:
              number: 80

Advantages:

Feature	Description
Domain routing	Different domains to different services
Path routing	/api and /web to different services
TLS termination	Unified HTTPS handling
Cost	Multiple services share one LB

For more detailed network explanation, see Kubernetes Network Architecture Guide.

DaemonSet, StatefulSet, Job

DaemonSet: Run one Pod on every Node

apiVersion: apps/v1
kind: DaemonSet
metadata:
  name: log-collector
spec:
  selector:
    matchLabels:
      app: log-collector
  template:
    metadata:
      labels:
        app: log-collector
    spec:
      containers:
      - name: fluentd
        image: fluentd:latest

Use cases: Log collection, monitoring agents, network plugins

StatefulSet: Stateful applications

Feature	Description
Stable network ID	pod-0, pod-1, pod-2
Stable storage	Each Pod has its own PVC
Ordered deployment	Start and stop in order

Use cases: Databases, distributed systems (Kafka, Elasticsearch)

Job / CronJob: One-time or scheduled tasks

# Job: Run once
apiVersion: batch/v1
kind: Job
metadata:
  name: backup-job
spec:
  template:
    spec:
      containers:
      - name: backup
        image: backup-tool:1.0
      restartPolicy: Never

# CronJob: Run on schedule
apiVersion: batch/v1
kind: CronJob
metadata:
  name: daily-backup
spec:
  schedule: "0 2 * * *"  # 2 AM daily
  jobTemplate:
    spec:
      template:
        spec:
          containers:
          - name: backup
            image: backup-tool:1.0
          restartPolicy: Never

---

FAQ: Common Questions

Q1: What's the difference between Pod and container?

Container is the actual running program. Pod is Kubernetes' scheduling unit, containing one or more containers.

Think of Pod as a "shell" for containers, providing shared network and storage.

Q2: When to use multi-container Pods?

Only when containers need to work closely together.

Criteria:

• Must these containers run together?
• Do they need to share filesystem?
• Is their lifecycle the same?

If all answers are "yes," use multi-container Pod. Otherwise use multiple single-container Pods.

Q3: What's the difference between Deployment and ReplicaSet?

ReplicaSet only maintains Pod count. Deployment adds rolling updates, rollback, and other features on top of ReplicaSet.

In practice, you'll almost always use Deployment directly.

Q4: ClusterIP, NodePort, LoadBalancer—how to choose?

Scenario	Choice
Internal service	ClusterIP
Development testing	NodePort
Production external	LoadBalancer or Ingress

Q5: If ConfigMap changes, does Pod auto-update?

Depends on usage method:

Method	Auto-update
Environment variables	❌ Need to restart Pod
Volume mount	✅ Will auto-update (with delay)

If using environment variables, Pod must be restarted after changing ConfigMap.

---

Next Steps

After learning these core objects, you can:

Goal	Action
Hands-on practice	Read Kubernetes Getting Started Tutorial
Deep dive networking	Read Kubernetes Network Architecture Guide
Understand architecture	Read Kubernetes Architecture Complete Guide
Choose tools	Read Kubernetes Tool Ecosystem Guide

---

Need Kubernetes adoption assistance?

From core object design to production deployment, CloudInsight provides complete technical support.

Book a consultation now

---

Further Reading

• Kubernetes Complete Guide - K8s introduction overview
• Kubernetes Architecture Complete Guide - Control Plane and Nodes
• Kubernetes Getting Started Tutorial - Practical step-by-step guide
• Kubernetes Network Architecture Guide - Service, Ingress explained
• Kubernetes Tool Ecosystem Guide - Helm, monitoring, CI/CD

---

References

• Kubernetes Official Documentation - Pod
• Kubernetes Official Documentation - Deployment
• Kubernetes Official Documentation - Service
• Kubernetes Official Documentation - ConfigMap
• Kubernetes Official Documentation - Secret
