AppSheet Automation Complete Tutorial | 4 Practical Examples [2025]

Your App is built, but you have to manually send notifications every time?

Automation makes your App work by itself.

New order comes in? Auto-send email. Low inventory? Auto-alert. Every morning? Auto-send report.

This tutorial teaches you how to set it up.

---

What is AppSheet Automation?

Explained in One Sentence

Automation is: When something happens, automatically execute an action.

For example:

• When "new order created", automatically "email the sales team"
• When "inventory below safety level", automatically "notify purchasing"
• When "8 AM every morning", automatically "send yesterday's report"

Why Do You Need Automation?

Without Automation, you have to remember to:

• Check if there are new orders
• Check if inventory is enough
• Manually compile reports every day

These repetitive tasks—Automation does them automatically for you.

What Can Automation Do?

Common applications:

Scenario	Trigger Condition	Action
New order notification	New data created	Send email
Approval reminder	Form submitted	Notify manager
Low inventory alert	Value below threshold	Send notification
Daily report	Fixed daily time	Send report
Expiration reminder	Date approaching	Send reminder
Status change notification	Field value changed	Notify relevant parties

Want to learn more AppSheet features? See AppSheet Complete Guide.

Automation Basic Concepts

Automation consists of three core elements.

Three Core Elements

1. Event - When to trigger?

Determines when Automation starts.

Common Event types:

Event Type	Description	Example
Data Change	Triggers on data change	Add, Update, Delete
Schedule	Triggers at fixed time	Daily, Weekly, Monthly
Form Submit	Triggers on form submission	User submits form

2. Process - What to do?

Defines the steps to execute.

A Process can include:

• One or more Tasks
• Conditional logic (If-Then)
• Multi-step flows

3. Task - Specific action

The actual action executed.

Common Task types:

Task Type	Description
Send Email	Send an email
Send Notification	Send push notification
Run Task	Execute another Task
Call Webhook	Call external API
Create PDF	Generate PDF document
Add Row	Add data row
Update Row	Update data

Event Details

Data Change Events

Trigger timing:

• Adds only: Only trigger on add
• Updates only: Only trigger on update
• Deletes only: Only trigger on delete
• All changes: Trigger on any change

Can add conditions, e.g.: "Only trigger when Status = 'Approved'"

Schedule Events

Set fixed schedules:

• Daily: Execute daily (can specify time)
• Weekly: Execute weekly (can specify day)
• Monthly: Execute monthly (can specify date)
• Custom: Custom Cron expression

Task Details

Send Email

Send email notifications.

Can configure:

• Recipient (fixed email or from data)
• Subject
• Body (supports dynamic fields)
• Attachments

Send Notification

Send in-app push notification.

User's phone will receive notification.

Call Webhook

Call external API.

Can be used for:

• Connect to LINE Notify
• Connect to Slack
• Trigger other systems

For advanced Webhook applications, see AppSheet API Integration Guide.

---

Automation Tutorials

4 practical examples teaching you to set up Automation from scratch.

Example 1: New Data Notification

Scenario: When new order comes in, auto-email sales team.

Step 1: Create Bot

1. Enter AppSheet editor
2. Click "Automation" on left side
3. Click "Create my first automation" or "+ New Bot"
4. Name it "New Order Notification"

Step 2: Configure Event

1. Click "Configure event"
2. Select "Data Change"
3. Table: Select "Orders"
4. Data change type: Select "Adds only"

Step 3: Configure Process

Click "Add a step" → "Run a task"

Step 4: Configure Task (Send Email)

1. Task type: Select "Send an email"
2. To: Enter sales email, or use formula [SalesEmail] from data
3. Subject: New Order Notification - <<[OrderID]>>
4. Body:

Hello,

A new order needs processing:

Order ID: <<[OrderID]>>
Customer Name: <<[CustomerName]>>
Order Amount: <<[TotalAmount]>>

Please process as soon as possible. Thank you!

Step 5: Test

1. Click "Test" button
2. Select test data
3. Confirm email sends correctly

Step 6: Enable

Switch Bot status to "On"

Example 2: Daily Report

Scenario: Every morning at 8 AM, auto-send yesterday's sales statistics.

Step 1: Create Bot

Name it "Daily Sales Report"

Step 2: Configure Event (Schedule)

1. Select "Schedule"
2. Frequency: Select "Daily"
3. Time: Select "08:00"
4. Timezone: Select your timezone

Step 3: Create Report View

First create a report View in UX → Views:

• Filter yesterday's data
• Include statistics

Step 4: Configure Task (Send Email with Report)

1. To: Manager email
2. Subject: Daily Sales Report - <<TODAY()-1>>
3. Body:

Good morning,

Here are yesterday's (<<TODAY()-1>>) sales statistics:

Total Orders: <<COUNT(SELECT(Orders[OrderID], [OrderDate] = TODAY()-1))>>
Total Sales: <<SUM(SELECT(Orders[TotalAmount], [OrderDate] = TODAY()-1))>>

See attachment for detailed report or log into system to view.

4. Attachment: Can attach PDF report

---

Example 3: Approval Workflow

Scenario: When leave request is submitted, auto-notify manager for approval.

Step 1: Create Bot

Name it "Leave Request Notification"

Step 2: Configure Event

1. Data Change → Adds only
2. Table: LeaveRequests
3. Condition (optional): [Status] = "Pending"

Step 3: Configure Task

Send email to manager:

1. To: [Employee].[Manager].[Email] (get from Employee→Manager→Email)
2. Subject: Leave Request Pending Approval - <<[Employee].[Name]>>
3. Body:

<<[Employee].[Manager].[Name]>>,

A leave request needs your approval:

Applicant: <<[Employee].[Name]>>
Leave Type: <<[LeaveType]>>
Dates: <<[StartDate]>> to <<[EndDate]>>
Days: <<[Days]>>
Reason: <<[Reason]>>

Please log in to approve.

Step 4: Add Approval Result Notification (Advanced)

Create another Bot:

• Event: Updates only, Condition = [_THISROW_BEFORE].[Status] <> [_THISROW_AFTER].[Status]
• When Status changes, notify applicant of result

---

Example 4: Expiration Reminder

Scenario: 30 days before contract expiration, auto-send reminder.

Step 1: Create Bot

Name it "Contract Expiration Reminder"

Step 2: Configure Event (Schedule)

1. Select "Schedule" → "Daily"
2. Check every morning

Step 3: Configure Process (with Condition)

1. Find contracts expiring within 30 days
2. Condition: [ExpiryDate] = TODAY() + 30

Step 4: Configure Task (Send Email)

1. To: Contract owner email
2. Subject: Contract Expiration Reminder - <<[ContractName]>>
3. Body:

Reminder,

The following contract will expire in 30 days:

Contract Name: <<[ContractName]>>
Customer: <<[CustomerName]>>
Expiry Date: <<[ExpiryDate]>>

Please evaluate renewal or take other action.

---

Automation setup too complex? Automation logic design requires experience. Schedule architecture consultation and let us help design optimal automated workflows.

---

Advanced Techniques

After learning the basics, let's look at advanced applications.

Conditional Execution

Let Automation decide whether to execute based on conditions.

Set Conditions at Event Level

Only triggers when conditions are met.

Example: Only notify manager for orders over 10,000

[TotalAmount] > 10000

Set Conditions at Process Level

Use If-Then branching.

Example: Send different notifications based on amount

IF [TotalAmount] > 50000 THEN
  Send to CEO
ELSEIF [TotalAmount] > 10000 THEN
  Send to Manager
ELSE
  Send to Sales

Multi-Step Workflows

One Bot can execute multiple Tasks.

Example: When new order comes in

1. Step 1: Email sales
2. Step 2: Notify warehouse
3. Step 3: Call Webhook to update ERP

Steps execute in sequence.

Error Handling

Configure how to handle Automation failures.

Common Errors:

• Email send failed
• Webhook connection failed
• Insufficient permissions

Handling Methods:

• Set retry count
• Send failure notification to admin
• Log errors

Webhook Integration

Call Webhook to connect external services.

Common Applications:

• LINE Notify to send LINE messages
• Slack to send channel messages
• Custom API to update other systems

For LINE integration tutorial, see AppSheet LINE Integration Tutorial.

Automation Limits

Know these limits before using Automation.

Plan Limits

Plan	Automation Support
Free	❌ Not supported
Starter	✅ Basic features
Core	✅ Full features
Enterprise	✅ Full features

Free plan cannot use Automation.

For detailed plan comparison, see AppSheet Pricing Complete Guide.

Execution Limits

Starter Plan Limits:

• Monthly execution count capped
• Some advanced Tasks not supported

General Limits:

• Webhook timeout: 30 seconds
• Email attachment size: 10MB
• Steps per Bot: Has limit

Feature Limits

What Automation cannot do:

• Complex programming logic (requires code)
• Real-time two-way conversation (chatbots)
• Large batch data processing

If needs exceed Automation capabilities, may need API integration with other tools.

---

FAQ

Does Automation cost extra?

Yes.

Free plan doesn't include Automation.

Requires Starter ($5/user/month) or above.

How many Bots can I create?

No explicit limit.

But recommendations:

• Keep Bot count minimal
• Combine related automations into one Bot
• Regularly review and clean up unused Bots

Does Automation trigger instantly?

Data Change type Events are instant.

Schedule type follows configured times.

Can I pause Automation?

Yes.

Each Bot can toggle On/Off status.

When paused, won't trigger, but settings are preserved.

How to debug Automation?

1. Use Test feature: Simulates execution without actually sending
2. Check Log: Automation → Select Bot → View execution history
3. Simplify flow: Test single steps first, confirm working before adding more

Can Automation trigger another Automation?

Yes, but be careful.

Use "Run Task" to trigger other Tasks.

Avoid infinite loops (A triggers B, B triggers A).

---

Next Steps

With Automation learned, your App can run automatically.

Practice Recommendations

1. Start simple: First make a "new data notification"
2. Add features gradually: After success, add conditions
3. Record issues: Note errors for troubleshooting

Continue Learning

• AppSheet Complete Guide: Learn all features
• AppSheet Examples Gallery: See more practical examples
• AppSheet API Integration Guide: Advanced external integration
• AppSheet LINE Integration Tutorial: Connect LINE notifications

---

Need More Complex Automation?

AppSheet Automation handles most needs, but complex multi-step workflows require professional planning.

Common advanced needs:

• Multi-system coordinated workflows
• Complex conditional logic
• Batch data processing
• Deep ERP/CRM integration

Schedule architecture consultation and let us help design optimal automation architecture.

---
